Design Support
M Seals offers an extensive design and engineering support service to meet your specific sealing applications.
We are sealing solutions experts and have over 60 years' engineering experience, solving problems and assisting clients with the following:
- Custom CAD seal design
- Application engineering support through site visits and online diagnosis
- Material recommendations
- Sealing system and groove design recommendations
- Research and development for seal improvement
- Correct installation and tool design guidance
- Product reference drawings for simplified goods-in inspection
- FEA analysis access
What information do we need?We generally ask you to supply us with the STAMPS information below. This allows our technical team and application engineers to choose an applicable material and suitable seal profile for your application.
- Speed(reciprocating and/or rotary)
- Temperature(both working and peek values)
- Application(details of the expected application)
- Media(fluid / gas to be sealed in both test and field environments)
- Pressure(both working and test values)
- Surface (confirmation of the surface finish of the mating hardware components)
Find out more
For more information about our seal design service, please contact us to speak to our technical team.
